FARGO DTC1500 ID Card Printer & Encoder

FARGO DTC1500 ID Card Printer & Encoder Specs: HID FARGO DTC1500 card printer and encoder offer the convenience and lower cost of high-capacity consumables along with a comprehensive feature set – enabling organizations to routinely issue highly secure cards and IDs at a fraction of the cost without sacrificing quality. Designed for government ID projects, universities and colleges, K-12 schools, healthcare facilities, and small-to-medium businesses, the DTC1500 boasts of distinctive security features ideal for these organizations. Print Method – Dye-sublimation / resin thermal transfer. Resolution – 300 dpi (11.8 dots/mm) continuous tone. Colors – Up to 16.7 million / 256 shades per pixel. Print Speed – 6 seconds per card (K*); 8 seconds per card (KO*); 16 seconds per card (YMCKO*); 24 seconds per card (YMCKOK*). Accepted Card Size – CR-80 (3.375 ̋ L x 2.125 ̋ W / 85.6 mm L x 54 mm W); CR-79 Adhesive Back (3.313 ̋ L x 2.063 ̋ W / 84.1 mm L x 52.4 mm W). Accepted Card Thickness – Print only: .009 ̋ – .040 ̋ / 9 mil – 40 mil / .229 mm – 1.016 mm; print / lamination: .030 ̋ – .040 ̋ / 30 mil – 40 mil / .762 mm – 1.02 mm. Print Area – CR-80 edge-to-edge (3.36 ̋ L x 2.11 ̋ W / 85.3 mm L x 53.7 mm W); CR-79 (3.3 ̋ L x 2.04 ̋ W / 83.8 mm L x 51.8 mm W). Accepted Card Types – PVC or polyester cards with polished PVC finish; monochrome resin required for 100% polyester cards; optical memory cards with PVC finish; rewrite. Input Hopper Card Capacity – Input card hopper (200 cards). Output Hopper Card Capacity – Up to 100 cards (.030 ̋ / .762 mm). Reject Hopper Card Capacity – Up to 100 cards (.030 ̋ / .762 mm) – same-side input/output card hopper or lamination module required. Communications Interface – USB 2.0 and Ethernet with the internal print server. Software Drivers – Windows® 10 (32 bit & 64 bit) / Windows® 7 / Windows® 8 (32 bit & 64 bit) / MAC OS X 10.5/10.6/10.7/10.8 / Linux. Display – User friendly, SmartScreenTM graphical display. Memory – 32 MB RAM. Encoding Options – 125 kHz (HID Prox) reader; 13.56 MHz (iCLASS, MIFARE, ISO 14443 A/B, ISO 15693) read/write encoder; Contact Smart Card Encoder reads from and writes to all ISO7816 1/2/3/4 memory and microprocessor smart cards (T=0, T=1) as well as synchronous cards; ISO Magnetic Stripe Encoding, dual high- and low-coercivity, Tracks 1, 2 and 3. Weight- Single – sided printer: 9 lbs / 4.1 Kg; dual-sided printer: 11 lbs / 5 Kg; printer lam: 20 lbs / 9.1 Kg. Dimensions – Single-sided printer: 9.8 ̋ H x 18.1 ̋ W x 9.2 ̋ D / 249 mm H x 460 mm W x 234 mm D Dual-sided printer: 9.8 ̋ H x 18.7 ̋ W x 9.2 ̋ D / 249 mm H x 475 mm W x 234 mm D Printer lam: 18.9 ̋ H x 18.7 ̋ W x 9.2 ̋ D / 480 mm H x 475 mm W x 234 mm D. Encoding Options – Supported smart card and magnetic stripe technologies: 125 kHz (HID Prox) reader; 13.56 MHz (iCLASS® Standard/SE/SR/Seos, MIFARE Classic®, MIFARE Plus®, MIFARE DESFire®, MIFARE DESFire® EV1, ISO 14443 A/B, ISO 15693) read/write encoder; contact smart card encoder reads from and writes to all ISO7816 1/2/3/4 memory and microprocessor smart cards (T=0, T=1) as well as synchronous cards; ISO magnetic stripe encoding, dual high- and low-coercivity, tracks 1, 2 and 3. Supported Access Control Credential Programming – iCLASS® Standard/SE/SR/Seos, MIFARE ClassicTM, MIFARE DESFire® EV1, HID Prox. Printer Options – Single-wire Ethernet and USB 2.0 interface for inline printing and encoding (note: single wire Ethernet encoding is only available for iCLASS®, MIFARE®, and contact smart card encoding); Ethernet-enabled printer supports wireless accessory; dual-sided printing module; same-side input/output card hopper; locking card input/output hopper; smart card encoding modules (contact/contactless); magnetic stripe encoding module; printer cleaning kit; Ethernet with internal print server; secure proprietary consumables system. Software – Swift ID embedded badging application, FARGO Workbench diagnostic utility with Color Assist spot-color matching. Printer Security – Printer access password protected. # Check Printers and Accessories
